Roadvision LED Rear Combination Lamp 10-30V Stop/Tail/Ind/Rev Jumbo 604x132mm
$174.95
Sale price
$174.95
Regular price
Skip to product information
Roadvision LED Rear Combination Lamp 10-30V Stop/Tail/Ind/Rev Jumbo 604x132mm
$174.95
Sale price
$174.95
Regular price
SP70BR601ARW
Roadvision LED Rear Combination Lamp 10-30V Stop/Tail/Ind/Rev Jumbo Triple Surface Mount 604x132mm - 5 years warranty
FEATURES
• Jumbo LED combination lamp range
• Multi-volt 10-30V DC input & low current draw
• Brighter than conventional incandescent systems
• 100,000 hour LED life span with solid state
technology
• Maintenance free
• High impact ABS housing & sealed polycarbonate lens
• Water and dust proof
• Pre-wired with 300mm LEDLink Connector
• Simple surface mount design
• Retro-fits in place of existing jumbo lamps
• ADR/ECE approved for all functions
Part NO:BR601ARW
Description: Rect Stop/Tail/Ind/Rev Lamp Triple Module
Functions: Stop/Tail/Indicator/Reverse/Reflector
Voltage Input: 10-30V DC
Number of LED's:ndicator - 24 LED’s
Stop/Tail - 24 LED’s
Reverse - 24 LED’s
Current Draw Amps:
Ind - 0.1A
S/T - 0.1/0.05A
Rev - 0.2A @ 13.8V
Dimensions AxBxC: 604x132x41mm
Lens Construction Polycarbonate
Housing Construction ABS High Impact
Mounting Type Surface Mount
Mounting Hole /Cut Out 501mm & 325mm
Cable Length:300mm LEDLink Connector
ADR Approval:Ind - CRN 46082
Stop - CRN 46121
Tail - CRN 46120
Rev - CRN 46122
CTA Approval: CTA-060773
