Roadvision LED Rear Combination Lamp 10-30V Stop/Tail/Ind/Rev Glow Park 274x100m
$86.95
Sale price
$86.95
Regular price
$129.00
SP70BR274ARW
Roadvision LED Rear Combination Lamp 10-30V Stop/Tail/Ind/Rev Glow Park 274x100mm - 5 Years Warranty
FEATURES
Stop/Tail Indicator, and Stop/Tail Indicator & Reverse functions
Retro Reflector incorporated into lens
Glow Park Lamp
Multi-volt 10-30V DC input & low current draw
100,000HR rated LED lifespan with solid state technology
Simple surface mount design
ADR/ECE approved for all functions
Light weight tough polycarbonate housing & lens
Part NO: BR274ARW
Description: Triple Combination Light, Stop/Tail Indicator & Reverse
Functions: Stop/Tail/Indicator & Reverse
Voltage Input: 10-30V DC
Number of LED's:
72 LEDs:
Indicator - 8 LEDs
Stop - 8 LEDs
Tail - 48 LEDs
Reverse - 8 LEDs
Current Draw Amps:
Ind - 0.3A, S/T - 0.5/0.6A, Rev - 0.5A @ 13.8V
Dimensions AxBxC: 274x100x35mm
Lens Construction Polycarbonate
Housing Construction ABS High Impact
Mounting Hole Centre： 241mm Stud Centres
Cable Length:300mm Sheathed
Wiring Colour Codes：Earth - White
Stop - Red
Tail - Brown
Indicator - Green or Yellow
Reverse - Black
ADR Approval:
Ind/Tail - E9-6R01/29-22458-00/E9-7R02/27-22458-00
Stop/Tail - E9-7R02/27-22456-00
Rev/Tail - E9-23R00/22-22459-00/E9-7R02/27-22459-00
CTA Approval: CTA-061091
